The Qianchuan Truck-mounted Water Well Drilling Rig belongs to the water well drilling rig series. With a crawler chassis it moves flexibly on complex terrain. It mainly drills with pneumatic DTH hammers and is suitable for domestic water wells, agricultural irrigation wells and geothermal air-conditioning holes, easy to operate with high penetration efficiency. See images for detailed specifications.
| Specification | Value |
|---|---|
| Truck equipped with Jinan Sinotruk 330 HP engine | Truck equipped with Jinan Sinotruk 330 HP engine |
| Drive configuration: 2-front-axle & 8-rear-axle drive (2×8 drive) | 2-front-axle & 8-rear-axle drive (2×8 drive) |
| Air compressor: Choosing opnions | Air compressor: Choosing opnions |
| Engine: Yuchai 265 kW engine | Engine: Yuchai 265 kW engine |
| Drilling rig equipped with: Yuchai 6108 engine | Drilling rig equipped with: Yuchai 6108 engine |
| Four-cylincler pump:63+63+63+25 | Four-cylincler pump:63+63+63+25 |
| Rotary motor:490+490 | Rotary motor:490+490 |
| Torque: 11000 N·m | Torque: 11000 N·m |
| Winch lifting capacity: 1.5 t | Winch lifting capacity: 1.5 t |
| Drilling rig lifting capacity: 26 t | Drilling rig lifting capacity: 26 t |
| Equipped with 250 hydraulic-driven mud pump | Equipped with 250 hydraulic-driven mud pump |
| Drilling diameter: 178-325 mm | Drilling diameter: 178-325 mm |
| Maximum pneumatic drilling depth: 500 m | Maximum pneumatic drilling depth: 500 m |
| Water drilling depth: 200-350 m | Water drilling depth: 200-350 m |
