The Qianchuan Model 300 Wheeled Water Well Drilling Rig belongs to the water well drilling rig series. With a crawler chassis it moves flexibly on complex terrain. It mainly drills with pneumatic DTH hammers and is suitable for domestic water wells, agricultural irrigation wells and geothermal air-conditioning holes, easy to operate with high penetration efficiency. See images for detailed specifications.
| Specification | Value |
|---|---|
| Main Engine Power | 58 / Yuchai |
| Drill pipe Length | 1.5 / 2.0 / 3.0 |
| Drilling depth | 300 |
| The Penetration Efficiency | 15-35 |
| Swing Torque | 5800-7700 |
| Hoisting Force of winch | 2 |
| Rapid rise Speed | 40 |
| Air Consumption | 17-31 |
| Climbing Angles | 30 |
| Dimension | 6000 × 2000 × 2550 |
| The Weight | 7.2 |
| Drill pipe diameter | 76 / 89 |
| Drilling hole Diameter | 140-355 |
| One-time Push rod Length | 3.0 |
| Swing Speed | 45-70 |
| Rig lifting Force | 18 |
| Rapid Lifting Speed | 26 |
| Working Air Pressure | 1.7-2.6 |
| Crawler Traction | 0-40 |
| Loading Width | / |
